Additive manufacturing simulation for faster, lower-cost process development
Material-Sim is a simulation tool for additive manufacturing. Through a simple user interface, it predicts and visualises how polymers such as PEEK cool, crystallise and deform as they are printed and annealed. It then uses those results to compensate the printed geometry and toolpaths in order to minimise defects like warpage.
With Material-Sim, engineers can quickly evaluate a process design with simulation and use the results to guide the next iteration. Ultimately, this allows them to reach a reliable process with fewer physical trials, in less time and at a lower cost.
- Temperature
- Compare print settings to keep the part within a target temperature range.
- Crystallinity
- Track how crystallinity develops through printing and annealing.
- Residual stress
- Find where stresses concentrate after cooling and test changes that reduce them.
- Warpage
- See how the part will warp and compensate the geometry to meet the required tolerances.
How warpage compensation works
Try the workflow yourself. Run through the four steps to see how compensating the geometry reduces warpage.
Warpage compensation demonstration
Loading simulation data.
Illustrative 100 mm wall, printed once from the nominal geometry and once from the compensated geometry. Interactive replay of precomputed simulation results. Shapes are magnified so the warpage is visible.
Simulate a full print
Explore temperature, crystallinity and distortion on the NIST CTC-02 housing, from printing through a hot-chamber hold, release and cooling.
CTC-02 housing
Loading results.
Illustrative simulation of a solid CTC-02 housing, approximately 144 × 180 × 84 mm, using a generic polymer material. This preview samples 38 of the 437 saved frames, including every frame after printing. The stages show printing, a hot-chamber hold, release and cooling. Times and temperatures are rescaled for illustration; each frame keeps its simulated colour pattern. These results have not been experimentally validated.
Why Material-Sim?
- Finite element solver built for AM
- Model layer-by-layer deposition, cooling and distortion in one simulation.
- Native semi-automated hex mesher
- Easily generate layered hexahedral meshes, ready for AM simulation.
- Simple browser interface
- Set up simulations and review results in a workflow designed for manufacturing engineers.
- Secure sign-in
- Sign in over HTTPS. Microsoft work-account sign-in is in preparation.
- Cloud compute
- Run demanding simulations on cloud hardware without a local high-performance computing system.
- Data security
- Project files and results are stored separately by account and encrypted at rest.
- Local deployment enquiries
- If your data needs to stay on site, ask us about running simulations and storing project files on your own network.
- PEEK process expertise
- Work with engineers focused on PEEK and other high-temperature polymers.
- GPU acceleration in development
- We’re developing GPU-accelerated solving for computationally demanding builds.
- Planned AI integration
- We plan to support the Model Context Protocol (MCP) so compatible AI assistants can connect to Material-Sim.
Become a development partner
We’re looking to partner with teams printing PEEK and other high-temperature polymers.
Bring us a challenging part or printing problem. We’d be happy to offer a free consultation to explore how simulation could help.
Get in touch
